Reis-class Submarine

Reis-class Submarine

Manufacturer: Gölcük Naval Shipyard
Category: Submarines
Add to Compare

Power Fuel-cell AIP + Diesel-Electric
Stealth Anechoic coating, quiet propulsion
Weapons 533 mm torpedoes, missiles, mines
Sensors Bow sonar, flank arrays, ESM suite

Full Specifications

1. General Information

Name / Class	Reis-Class (Type 214TN)
Country of Origin	Turkey / Germany
Type	Diesel-Electric AIP Attack Submarine
Manufacturer	Gölcük Naval Shipyard / TKMS
Operators	Turkish Navy
In Service	2025 (expected first unit)
Status	In production

2. Dimensions & Design

Length	~67.6 m
Beam (Width)	6.3 m
Draught / Draft	6.0 m
Displacement (Surfaced)	~1,700 tons
Displacement (Submerged)	~1,950 tons
Hull Material	Non-magnetic steel
Crew	~27–30

3. Propulsion & Performance

Power Source	Diesel-Electric + AIP
Engine / Reactor Type	Siemens PEM Fuel-Cell
Propulsion System	Single shaft, skewed propeller
Speed (Surfaced)	~12 knots
Speed (Submerged)	~20 knots
Range	~12,000 km (surfaced)
Endurance	Several weeks on AIP
Operational Depth	~250+ m
Test Depth	~400 m
Maximum Depth	Classified

4. Armament

Torpedo Tubes	8 × 533 mm
Torpedoes / Missiles	DM2A4, Harpoon ASM
Cruise / Ballistic Missiles	None
Mines	Yes
Decoys / Countermeasures	Acoustic decoys, ECM

5. Sensors & Electronics

Sonar System	Bow, flank arrays, passive/active sonar
Radar	Navigation radar
Combat Management System	ISUS-90/72 + Turkish upgrades
Electronic Warfare System	ESM, electronic countermeasures
Communication Systems	VLF/UHF/SATCOM
Navigation Systems	GPS/INS

6. Stealth & Defense

Anechoic Coating	Yes
Noise Reduction Features	Quiet propulsion, dampened mounts
Magnetic Signature Reduction	Yes
Acoustic Signature Level	Very low

7. Payload & Capacity

Weapons Payload	Torpedoes, missiles, mines
Special Forces Accommodation	Yes
UUV / Drone Capability	Limited

8. Notable Technologies

Reactor / AIP Type	Siemens PEM Fuel-Cell
Automation Level	High
Special Features	Low-magnetic hull, long-endurance submerged ops

9. Operational History

Major Deployments	Not yet operational
Combat / Exercises	N/A
Upgrades	Turkish-developed combat systems planned

10. Cost & Production

Unit Cost	~$550–650 million
Number Built	6 planned
Production Period	2015–2030

11. Media & Credits

Image / Video Source	Turkish Navy / SSB
Official Website	Turkish Ministry of Defense
Reference Credit	Open-source defense publications

Our Rating

The overall rating is based on review by our experts

7.8

Combat Effectiveness 7 / 10
Electronic Warfare 8 / 10
Technology 8 / 10
Range & Endurance 8 / 10

PROS

Advanced fuel-cell AIP system enables long submerged endurance
Low acoustic signature and modern stealth shaping
Strong multi-mission capability for littoral operations
Modern sensors and integrated combat suite
High automation improves crew efficiency

CONS

Limited top speed compared to nuclear submarines
Dependence on foreign technology for key systems
Small payload compared to heavier attack submarines
Limited strategic range due to diesel-electric architecture
Not equipped for ballistic missile operations

Reis-Class AIP Attack Submarine

The Reis-class submarine, Turkey’s latest generation air-independent propulsion (AIP) attack submarine, represents a major leap forward for the Turkish Navy’s underwater warfare capabilities. Based on the German Type 214TN design, the class integrates advanced stealth shaping, fuel-cell AIP technology, and modern combat systems tailored for littoral and deep-water operations. Built by Gölcük Naval Shipyard in partnership with thyssenkrupp Marine Systems (TKMS), the program significantly boosts Türkiye’s maritime deterrence in the Mediterranean, Aegean, and Black Sea regions.

Equipped for multi-mission roles, the Reis class excels in anti-surface warfare, anti-submarine warfare, intelligence gathering, and special operations deployment. Its hydrogen fuel-cell AIP system allows the submarine to remain submerged far longer than conventional diesel-electric boats, offering weeks of silent operation with minimal acoustic signature. This makes the platform especially relevant to U.S. and NATO naval watchers monitoring developments in the region.

The submarine carries eight 533 mm torpedo tubes, supporting heavyweight torpedoes, anti-ship missiles such as the Harpoon, and naval mines. Advanced sonar arrays, flank sensors, and integrated combat management systems enable high-fidelity tracking and engagement in cluttered coastal environments.

With a modern hydrodynamic hull, low-magnetic steel structure, and extensive acoustic dampening, the Reis class is optimized for stealth. Crew efficiency is enhanced through high automation levels, reducing workload while improving mission endurance. As Turkey expands its indigenous defense production, the class serves as a stepping-stone toward fully domestic submarine manufacturing.

Overall, the Reis-class submarine provides a capable, modern, and stealth-focused platform that aligns closely with NATO operational standards and reflects the Turkish Navy’s ongoing modernization strategy.

Reis-class Submarine Price

While the Reis-class submarine is not exported to the United States, its estimated unit cost—derived from the Type 214 program—ranges between $550–650 million, depending on configuration, sensors, and weapons packages.
