AN/TPS 59 Long Range Air Surveillance Radar

The AN/TPS 59 radar is a long range, land-based air surveillance and ballistic missile defense system developed to provide early warning of aircraft and missile threats. Its 360-degree coverage and high-altitude detection make it a key asset for theater air defense and ballistic missile tracking missions. The system is operational with the U.S. Marine Corps and allied forces, and has been deployed internationally for expeditionary defense.

Manufacturer

Originally developed by Hughes Aircraft Company and now produced by Lockheed Martin, the AN/TPS 59 has evolved through multiple upgrades to support modern air and missile defense missions. Lockheed Martin also provides training, maintenance, and integration support for international users.

Speed and Range

The radar tracks high-speed targets, including tactical ballistic missiles, at ranges exceeding 740 kilometers. It can monitor low-flying aircraft, UAVs, and high-altitude ballistic trajectories simultaneously. Its electronic beam steering and wide elevation coverage enable near real-time detection and cueing of defensive systems.

Cost / Price

Exact pricing is classified, but open source estimates place the system in the tens of millions of U.S. dollars, depending on configuration, export requirements, and support packages.

Operational Role

AN/TPS 59 supports air surveillance, ballistic missile warning, and integration with air defense networks such as Patriot and Aegis. In recent years, Lockheed Martin delivered the AN/TPS‑59(V)3B radar to Bahrain under a U.S. Foreign Military Sale, where it completed site acceptance tests and became operational with the Bahrain Defence Force. Personnel were trained at Lockheed Martin’s Syracuse facility, ensuring effective deployment and operation.

TPS-77 MRR Long Range Air Surveillance Radar

The TPS-77 Multi Role Radar is a modern long range air surveillance system designed to give air forces reliable early warning and airspace control in contested environments. Built for mobility and survivability, the radar supports national air defense, expeditionary operations, and joint force integration. It is widely used by U.S. allies for persistent monitoring of aircraft, cruise missiles, and unmanned threats.

Manufacturer

The TPS-77 MRR is developed and produced by Lockheed Martin, a U.S. defense prime contractor with deep experience in radar, sensors, and integrated air and missile defense systems.

Speed and Range

The radar is optimized for long range detection rather than speed tracking of a single target type. It can detect and track fast moving fighter aircraft, ballistic trajectories at altitude, and low flying cruise missiles. Maximum instrumented detection range exceeds 470 kilometers, with full 360 degree azimuth coverage and high elevation tracking for layered air defense.

Cost / Price

Exact pricing depends on configuration, logistics, and support packages. Open source estimates place unit costs in the tens of millions of U.S. dollars, typically bundled within broader air defense or command and control programs.

Operational Use

TPS-77 MRR supports air sovereignty missions, early warning, ground controlled interception, and integration with surface to air missile systems. Its solid state AESA design improves reliability while reducing maintenance demands in harsh climates.

FAQs

TPY 4 RADA Multi Mission Air Defense Radar

The TPY-4 is Lockheed Martin’s next generation ground based air surveillance radar, developed to strengthen national and NATO integrated air and missile defense networks. Designed to replace aging Cold War era sensors, TPY-4 delivers persistent, long range detection against modern air threats, including aircraft, cruise missiles, and unmanned aerial systems. Its fully digital AESA architecture allows continuous 360 degree coverage while supporting high target density environments.

Selected by Denmark to reinforce NATO deterrence and regional air defense, TPY-4 reflects Lockheed Martin’s focus on scalable, networked sensors optimized for coalition operations and U.S. aligned command and control systems.

Manufacturer

TPY-4 is manufactured by Lockheed Martin, a U.S. based defense and aerospace company. The radar is developed and produced in the United States, with European industrial participation for selected international programs. Lockheed Martin is responsible for system design, radar technology, software, and integration.

Speed and Range

AN/TPY-4 provides detection ranges of up to 450 kilometers against large aerial targets. The radar supports high update rates and simultaneous tracking of hundreds of targets, including high speed and low altitude threats. Electronic beam steering enables rapid repositioning without mechanical movement, improving survivability and reaction time.

Cost / Price

Lockheed Martin has not released official pricing. Based on comparable long range AESA surveillance radars, open source estimates place AN/TPY-4 unit cost in the tens of millions of U.S. dollars, depending on configuration and support packages.

FAQs

AN TPQ 53 Counterfire Radar System

The AN TPQ 53 radar system is a modern counterfire sensor built to protect US and allied forces from indirect fire threats. Designed for fast moving and contested battlefields, it gives commanders rapid warning and accurate firing point data against rockets artillery and mortars.

Developed by Lockheed Martin in the United States, AN TPQ 53 replaces older counterfire radars with a single system able to handle short range and long range missions. It uses an active electronically scanned array radar to search wide areas while tracking multiple threats at once. The system can be deployed in minutes and relocated quickly to avoid enemy targeting.

Core Mission and Capabilities

AN TPQ 53 is optimized for counter rocket artillery and mortar missions. It detects incoming rounds shortly after launch, calculates their point of origin, and shares that data with fire control networks. Detection ranges reach up to 60 kilometers for rockets, with shorter but highly precise coverage for mortars and artillery shells.

The radar supports 360 degree surveillance through rapid sector scanning. Its AESA antenna allows fast beam steering without moving parts, improving reliability and update rate. Advanced signal processing helps reject clutter and maintain performance in complex terrain and weather.

Operational Use and Integration

The system is fully networked with US Army battle management systems, including FAAD C2 and AFATDS. It is mounted on a tactical vehicle and can operate with a small crew, reducing manpower needs. AN TPQ 53 has seen operational use with US forces and partners in active combat zones, where counterfire speed directly saves lives.

AN TPQ 53 Radar System Price in United State

The AN/TPQ-53 Radar System price in the United States is not officially published. Open source defense budget data suggests a unit cost in the range of USD 15 to 20 million depending on configuration support equipment and contracts.
